Teadit NA 1005 Gasket Specification Sheet
Find a wide variety of the widest selection of Sheet Gaskets.
Description: TEADIT style NA-1005 is a compressed non-asbestos jointingsheet material produced from Aramid fiber, bonded with Nitrile Rubber (NBR). It is being manufactured by means of a calender heat process under strict quality control standards registered under ISO 9001 certification. Application/service: TEADIT style NA-1005 is indicated for air, brine, water, low pressure steam, weak organic and inorganic acids , diluted and concentrated alkalis, petroleum derivatives, synthetic and vegetable oils, aliphatic and chlorinated solvents, refrigerants, gases and chemical products in general. Product standard: • Thickness: 0.5 / 1.0 / 1.5 / 2.0 / 2.5 and 3.0 mm • Sheet size: 1,500 x 1,600 mm, 1,500 x 3,200 mm Technical data: • Peak temperature: +400 °C • Constant temperature: +240 °C • Peak pressure: 110 bar • Constant working pressure: 50 bar • Color: blue (other colors upon request).
For more information please contact:
Lucky : 081210121989
Office : LTC Lt.GF 1 Blok C25 No.7 Jl. Hayam Wuruk No.127 West Jakarta 11180
Branch : LTC Lt.GF 1 Blok RB No.23 Jl.Hayam Wuruk No.127 West Jakarta 11180
